Recording Rate: 120 fps / 100 fps (NTSC / PAL)
-
Display Rate: 120 fps / 100 fps (NTSC / PAL)
| Specifications | ||
| Input Type | BNC | BNC X 4 |
| D-Type | DB15 X 2 | |
| Video Input(s) | 4, 8, 12, 16 Cams | |
| Audio Input(s) | 4 Channels | |
| Total Recording Rate At 320 X 240 Resolution / MPEG4 (ASP) |
120 fps (NTSC), 100 fps (PAL) | |
| Display Rate | 120 fps (NTSC), 100 fps (PAL). | |
| Video Resolution - NTSC/PAL | Full D1, Half D1, CIF | |
| Compression Format | Geo MPEG4, Geo MPEG4 (ASP), Geo H264, Geo H264 V2 | |
| GV-A16 Support | Yes | |
| GV-NET Card Support | Yes | |
| GV-NET/IO Card Support | Yes | |
| Dimensions (W x H) | BNC | 152 x 101 ( mm) / 5.98 x 3.98 (in) |
| D-Type | 174 x 107 ( mm) / 6.85 x 4.21 (in) | |
| Installation Guide | Single Card & Two Cards | |
| Note: GV-800 is currently not compatible with VIA series and ATI series chipset motherboards. | ||
| Minimum System Requirements For One Card | ||
| OS Supported | 32-bit | Windows XP / Windows Vista / Windows 7 / Windows Server 2008 |
| 64-bit | Windows 7 / Windows Server 2008 | |
| CPU | Pentium 4, 3.0 GHz with Hyper-threading | |
| RAM | Windows XP: 2 x 512 MB Dual Channels Windows Vista / 7 / Server 2008 : 2 x 1 GB Dual Channels |
|
| HDD | 80 GB | |
| VGA | ATI Radeon X600 NVIDIA 6200 |
|
| DirectX | 9.0c | |
| Minimum System Requirements For Two Cards | ||
| OS Supported | 32-bit | Windows XP / Windows Vista / Windows 7 / Windows Server 2008 |
| 64-bit | Windows 7 / Windows Server 2008 | |
| CPU | Pentium 4, 3.0 GHz Dual Core | |
| RAM | 2 x 1 GB Dual Channels | |
| HDD | 160 GB | |
| VGA | ATI Radeon X1300 PCI-E NVIDIA GeForce 7300 PCI-E |
|
| DirectX | 9.0c | |
