Recording Rate: 60 fps / 50 fps (NTSC / PAL)
-
Display Rate: 60 fps / 50 fps (NTSC / PAL)
Specifications | ||
Input Type | D-Type: DB15 X 2 | |
Video Input(s) | 4, 8, 12, 16 Cams | |
Audio Input(s) | 2 Channels | |
Total Recording Rate At 320 X 240 Resolution / MPEG4 (ASP) |
60 fps (NTSC), 50 fps (PAL) | |
Display Rate | 60 fps (NTSC), 50 fps (PAL) | |
Video Resolution -NTSC/PAL | Full D1, Half D1, CIF | |
Compression Format | Geo MPEG4, Geo MPEG4 (ASP), Geo H264, Geo H264 V2 | |
GV-A16 Support | Yes | |
GV-NET Card Support | Yes | |
GV-NET/IO Card Support | Yes | |
Dimensions (W x H) | D-Type : 174 x 107 (mm) / 6.85 x 4.21 (in) | |
Installation Guide | Single Card & Two Cards | |
Note: GV-650 is currently not compatible with VIA series and ATI series chipset motherboards. | ||
Minimum System Requirements For One Card | ||
OS Supported | 32-bit | Windows XP / Windows Vista / Windows 7 / Windows Server 2008 |
64-bit | Windows 7 / Windows Server 2008 | |
CPU | Pentium 4, 2.4 GHz with Hyper-threading | |
RAM | Windows XP : 2 x 512 MB Dual Channels Windows Vista / 7 / Server 2008: 2 x 1 GB Dual Channels |
|
HDD | 80 GB | |
VGA | ATI Radeon X600 NVIDIA 6200 |
|
DirectX | 9.0c | |
Minimum System Requirements For Two Cards | ||
OS Supported | 32-bit | Windows XP / Windows Vista / Windows 7 / Windows Server 2008 |
64-bit | Windows 7 / Windows Server 2008 | |
CPU | Pentium 4, 2.8 GHz with Hyper-threading | |
RAM | 2 x 1 GB Dual Channels | |
HDD | 160 GB | |
VGA | ATI Radeon X600 NVIDIA 6200 |
|
DirectX | 9.0c |
